Brief Introduction

3500/25-01-03-01

Bently 3500/25 improved keyphasor moduleCommonly used models3500/25-01-01-003500/25-02-01-003500/25-01-03-003500/25-01-01-013500/25-02-01-013500/25-01-03-01The improved keyphasor module is an updated and upgraded 3500 System Module. It extends the key phase signal processing capabilities while retaining the form of the existing key phase.3500/25 The improved key phase module is a half-height, 2-channel module used to provide the key phase signal to the monitor module in the 3500 frame. The module receives an input signal from an eddy-current sensor or electromagnetic sensor and converts this signal into a digital key phase signal that indicates when a key phase mark on the shaft passes through the key phase probe. The 3500 mechanical protection system can receive 4 key phase signals.
