Brief Introduction

3500/32-01-01

Bently 3500/32 relay moduleCommonly used models3500/32-01-003500/32-01-01The Bently 3500 four-channel relay module provides the output of four relays. Any number of 4-channel relay modules can be placed in any of the slots to the right of the frame interface module. Each output of the 4-channel relay module can be programmed independently to execute the required voting logic. Each relay used in a 4-channel relay module has an "alarm drive logic". This alarm actuation logic can be programmed with "and" and "or gate" logic and can utilize the alarm input (warning or hazard) provided by any monitor channel in the frame or a combination of any of the monitor channels. The alarm-driven logic application framework is configured with software programming to meet the specific needs of the application.3500/32 -AXX-BXXDescription of the optionA: Output module 0 1 4 channel relay I/O moduleB: Approve the Institution Option0 0 No 0 1 CSA/NRTL/CSpare parts125712-01 4 Channel Relay Module Spare Part.()125720-01 4 Channel Relay I/O Module Spare Part04425545 Grounding Bracelet (Single Purpose)132319-01 TOUGHNESS IC04400037 IC removal tool00580436 connector, internal terminal, 6-pos., green129771-01 4-Channel Relay Module ManualIn addition to any alarm relay, a universal system OK Relay 2 is also available in the frame. This relay is located in the RIM and is connected to the OK circuit of all modules in the frame. These circuits monitor the operating status of each module. The OK relay will notify you of any malfunction in the field wiring of the module and its sensors or associated sensors, which is a single pole double throw (SPDT) type, usually live, and provides an additional notification function when the main power supply fails.
